Tree inference

library(treepplr)
library(dplyr)
library(ggplot2)
library(ape)

Load model and data files

Load the tree inference model and example data available within treepplr.

model <- tp_model("tree_inference")
data <- tp_data("tree_inference")

The data in this example is a toy dataset …

str(data)
#> List of 1
#>  $ data: int [1:4, 1:15] 1 1 0 0 1 1 0 0 0 0 ...

Run TreePPL

Now we can compile and run the TreePPL program. The function tp_treeppl() has many optional arguments to change the inference method used. Here, we will use

output_list <- tp_treeppl(model = model, data = data, method = "smc-apf",
                          samples = 1000, subsample = 5, resample = "manual",
                          n_runs = 10)

The result is a list of sweeps, each one containing 3 elements: the sampled parameter values and the weights (in log scale) for each of the 5 particles in each sweep, and the normalizing constant for the whole sweep.

str(output_list,max.level = 2)
#> List of 10
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.1
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.3
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.4
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.3
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.5
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.4
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.4
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.4
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.5
#>  $ :List of 3
#>   ..$ samples  :List of 10
#>   ..$ weights  :List of 10
#>   ..$ normConst: num -79.4

Plot the posterior distribution

In this example we will check that the different runs converged to the same posterior, by checking the variance in the normalizing constant among runs.

tp_smc_convergence(output_list)
#> [1] 0.01258822

There are different ways to summarize the posterior distribution of trees. In this examples, we calculate the the MAP (Maximum A Posteriori) tree. We do this by finding the single tree topology that has the highest posterior probability, and then using ape::consensus to compute average branch lengths for all sampled trees with the MAP topology.

out_trees <- tp_json_to_phylo(output_list)

map_tree <- tp_map_tree(out_trees)
#> [1] "MAP Topology found"
#> [1] "Posterior Probability: 0.8164"
#> [1] "Based on the topology of 83 samples out of 100"
plot(map_tree)
axisPhylo()
